Product features
Maximum Resolution : 3840 x 2160
Minimum Illumination : F1.2, 0 lux (IR LED on)
Field of View (H) : 97.5 - 38.5
Day/Night : IR cut filter
White Balance : Auto, Indoor, Outdoor, Manual
Compensation : DWDR / BLC / HLC
Electronic Shutter Speed : 1/25 - 1/100000 sec.
DNR : 2D / 3D
3840x2160 / 2560x1440 / 2304x1296 /
1980x1080 / 1280x720 @ 30fps
Bitrate Control : VBR, CBR
Multiple Streaming : 3 streams
IPv4, IPv6, TCP, UDP, RTP, RTSP, HTTP, SMTP, FTP, DHCP
User ID & Password protection, IP/Mac address filtering,
digest authentication
Max. 10 simultaneous users, Actual number of users may
vary depending on bandwidth
Mono Output : G.711A / G.711U
PC Application : SecureGuard VMS
Mobile : SecureGuard Mobile (iPhone and Android)
Analog Video Output : BNC
Alarm : 1 sensor input, 1 relay output (terminal block)
Audio : 1 mic in, 1 line out (3.5mm)
Storage : Micro SD slot
Power : DC jack
External Control : RS485 (terminal block)
Motion detection, object removal, abnormality,
line crossing, intrusion
Alarm : Events FTP upload, email upload
Image Settings : Privacy mask, region of interest, OSD
Power Consumption : 8W
Operating Temperature : -4F - 122F
Operating Humidity : 0% - 90% RH
Unit Dimensions : 4.3 (Dia.) x 11.2 (D)
Unit Weight : 2.5 lbs.
Junction Box Dimensions : 4.4 (Dia.) x 1.6 (H)
Junction Box Weight : 8 oz.
Certifications : FCC, RoHS
