AETEK SD-101, 2.5G PoE++ Surge Protector, 20KV/10KA, Part# 640460
Surge protector

AETEK SD-101, 2.5G PoE++ Surge Protector, 20KV/10KA, Part# 640460

Availability: In Stock
$50.23
Wishlist Compare

The efficient AETEK 640460 SD-101, 2.5G PoE++ Surge Protector, 20KV/10KA, is a 1-Channel, IEEE 802.3af/at/bt & UPoE, Surge Protector that protects against surges up to 20KV/10KA and supports Multi-Gig 10/100/1000/2500 Mbps.

Features:

  • Supports 10M/100M/1G/2.5G bps Ethernet
  • Complies with IEEE 802.3bt/at/af and UPoE standards
  • Protects up to 20KV/10KA surge protectionAn
  • LED that indicates a failure situation
  • Metal housing



Specifications:

Standards and Certifications

    • - 802.3af / 802.3at / 802.3bt
    • - CE, FCC, VCCI, C-Tick
    • - ITU-T K.21, IEC-61643-21, IEC-61000-4-5, TIA-968-A (FCC Part68)

General

    • Number of Ports: 1
    • Connectors: 2 x RJ45
    • Data transfer rate: 10M/100M/1G/2.5G bps
    • Max Discharge Current (8/20us): 10KA
    • Maximum Operation DC Voltage: 60VDC
    • Maximum Operation DC Current: 1A for 2 pair, 2A for 4 pair, 95W maximum
    • Line to Ground Protection Level (10/700us): 20KV
    • Line to Line Protection Level: (10/700us): 4KV
    • Clamping Voltage (Line to GND):
    • Line to Line Protection Level: 600V
    • Clamping Voltage (Line to Line): 20V
    • Insertion Loss @ 10MHz/100MHz: 1 dB
    • Return Loss @ 10MHz/100MHz: -20db
    • Response time: 1ns
    • MTBF (Hours): 923,617
    • Operating Altitude: 2,000 m (6,562 ft)



Dimensions: 3.15 x 1.57 x 0.98 inches

"A minimum order amount of $50 is required in order to Maintain Wholesale Price"



NEW IN THE BOX
