AETEK SD-201, Outdoor 2.5G PoE++ Surge Protector, 20KV/10KA, Hardened Grade IP67, Part# 640477
Surge protection

AETEK SD-201, Outdoor 2.5G PoE++ Surge Protector, 20KV/10KA, Hardened Grade IP67, Part# 640477

Availability: In Stock
$74.26
Wishlist Compare

The quality AETEK 640477 SD-201, Outdoor 2.5G PoE++ Surge Protector, 20KV/10KA, Hardened Grade IP67 is a 1 Channel, IEEE 802.3af/at/bt & UPoE, Protects against surges up to 20KV/10KA, Multi-Gig 10/100/1000/2500 Mbps.

Features

  • Supports 10M/100M/1G/2.5G bps Ethernet
  • Complies with IEEE 802.3bt/at/af and UPoE standards
  • Protects up to 20KV/10KA surge protection
  • An LED that indicates a failure situation
  • Metal enclosure with an IP67 rating
  • Temperature range of -40 degrees to 185 degrees Fahrenheit



Specifications:

Standards and Certifications

  • 802.3af / 802.3at / 802.3bt
  • CE, FCC, VCCI, C-Tick
  • ITU-T K.21, IEC-61643-21, IEC-61000-4-5, TIA-968-A (FCC Part68)


General

  • Number of Ports: 1
  • Connectors: 2 x RJ45
  • Data transfer rate: 10M/100M/1G/2.5G bps
  • Max Discharge Current (8/20us): 10KA
  • Maximum Operation DC Voltage: 60VDC
  • Maximum Operation DC Current: 1A for 2 pair, 2A for 4 pair, 95W maximum
  • Line to Ground Protection Level (10/700us): 20KV
  • Line to Line Protection Level: (10/700us): 4KV
  • Clamping Voltage (Line to GND): 150V
  • Clamping Voltage (Line to Line): 20V
  • Insertion Loss @ 10MHz/100MHz: 1 dB
  • Return Loss @ 10MHz/100MHz: -20db
  • Response time: 1ns
  • MTBF (Hours): 1,132,887
  • Operating Altitude: 2,000 m (6,562 ft)

Dimensions: 7.33 x 1.97 x 1.26 inches



" A minimum order amount of $50 is required in order to Maintain Wholesale Price"

NEW IN THE BOX
