Manhattan Steam Deck Travel Dock and 52W USB Charger - Two USB-C and Two USB-A Ports, Part# 130554
USB Hubs & Converters

Manhattan Steam Deck Travel Dock and 52W USB Charger - Two USB-C and Two USB-A Ports, Part# 130554

Availability: In Stock
$8.40
Wishlist Compare

The efficient Manhattan 130554 Steam Deck Travel Dock and 52W USB Charger - Two USB-C and Two USB-A Ports is a USB C PD Charger 45 W and USB C to HDMI Multiport Dock with 2 x USB C and 2 x USB A ports, compact travel docking station with internal power supply, for Chomebook, Surface and Laptop.

It has one HDMI Port, One USB-C Power Delivery Port up to 45 W, One USB-C Port up to 5 V/1 A, Two USB 3.2 Gen 1 Type-A Ports, Detachable Power Cable, in color Black.

Features:

  • Multiport dock and power supply for Valve's Steam Deck
  • Fast-charge your Steam Deck all full speed, connects your Steam Deck to external monitor via HDMI and connects your mouse and keyboard to your Steam Deck
  • The perfect solution for those who travel and take their Steam Deck with them.
  • Lets your smartphone work like a desktop PC* while also charging it



Specifications:

Standards and Certifications

  • DP 1.2 over USB-C
  • Power Delivery 2.0
  • USB 3.2 Gen 1
  • HDCP 1.4
  • CE
  • FCC
  • RoHS

General

  • Video Resolutions: 640x480, 800x600, 1024x768, 1920x1200, 1920x1080
  • USB-A data transfer speeds: 5 Gbps
  • USB-A charging: BC 1.2 with 1 A
  • USB-C port 1 charging: up to 5 W (5 V/1 A)
  • USB-C port 2 charging: up to 45 W

Electrical

  • AC input: 100 – 240 V; 50 – 60 Hz
  • Voltage/current settings (maximum):
    - USB-C PD 45 W:
    - 5 V / 3 A
    - 9 V / 3 A
    - 12 V / 3 A
    - 15 V / 3 A
    - 20 V / 2.25 A
    - USB-C 5 W:
    - 5 V / 1 A
    - USB-A:
    - 5 V / 1 A

Input Characteristics

  • AC rated voltage: 100 – 240 V
  • Frequency range: 50 – 60 Hz

Output Characteristics

  • Rated power: 52.5 watts maximum
  • Overshoot voltage: ≤ 5%

Protection Characteristics

  • Short-circuit (SCP) with auto-recovery mode
  • Overvoltage (OVP) with auto-recovery mode
  • Overcurrent (OCP) — current limit: 150% (max)
  • Over-temperature (OTP)

Physical

  • Housing: 80 x 63 x 30 mm (3.14 x 2.48 x 1.18 in.)
  • Power cable length: 1.8 m (6 ft.)
  • Weight: 216 g (7.61 oz.)

Operating Environment

  • Operation temperature: 0 – 30°C (32 – 86°F)
  • Storage temperature: -20 – 70°C (-4 – 158°F)
  • Humidity (noncondensing): 5 – 95% RH

System Requirements

  • Windows 7/8.1/10/11, Android, Mac, ChromeOS

Package Contents

  • Compact Travel Dock With PD Charger
  • 1.8 m (6 ft.) power cord
  • 0.5 m (1.5 ft.) USB-C male to USB-C male cable
  • Quick Instruction Guide

Dimensions: 3.15 (L) x 2.5 (W) x 1.18 (H) inches
